Self Lubricating Flanged Bush FMB2021.5 PAF Bearing

Name: Self Lubricating Flanged Bush FMB20215 PAF Bearing
Brand: Bushing Inch Size
Price: 0.1 USD

China Self Lubricating Flanged Bush FMB2021.5 PAF Bearing factory

Brand Name : Bushing Inch Size

Model Number : INCH SIZE BUSHING

Certification : STEEL BACKED BUSHING, DIN 1494 / ISO 3547, LOW-MAINTENANCE

Place of Origin : Steel Backed Bushings

MOQ : negotiable

Price : usd0.1?/pcs，negotiable

Payment Terms : T/T IN ADVANCE, Western Union

Supply Ability : Bushing Inch Size Dry Bushes Boccole Equivalent Manufacturers Self Lubricating Plain Bearings Suppliers

Delivery Time : 10-15 work days

Packaging Details : EXPORT BUSHING CARTONS WOODEN CASES

Material : carbon steel + bronze+

Lubricating : Self Lubricated Lined

Service : OEM Customized Services, OEM, Prompt Delivery

Feature : Split Bush Bearing - Flanged

Code : BUSHINGS steel bushing sleeve

Find your dimensions : metric size and inch size

Wrapped Bush : Low Friction Bushing Bush

Bearing Bushing Factory Price : tiffany@viiplus.com

Self-lubricating Bearing Bushing Manufacturer : https://www.viiplus.com/

High Light : Coated Self Lubricating Plain Bearing, ptfe Self Lubricating Plain Bearing, Steel Backed Self Lubricating Plain Bearing

characteristic : Втулки скольжения (биметаллические подшипники скольжения)

Dry slide bearing : Self Lubricating Plain Bearing Work in High Temp & Submerged Applications Where Grease, Oil & Plastics Fail. Reduced costs & downtime. Non-galling. Increased reliability. Run dry & keeps running.

Bush Bearings Manufacturers Suppliers Exporters : plain bearings. Long, maintenance-free service, manufactures bushings in various designs and from different materials. tiffany@viiplus.com, Bushings - Configure and purchase - https://www.viiplus.com/

Contact Now

The Self-Lubricating Flanged Bush FMB2021.5 PAF Bearing is a high-performance bearing solution designed to provide smooth and reliable operation in various industrial applications.

The key feature of this bearing is its self-lubricating property, which significantly reduces the need for regular lubrication. This not only saves time and effort in maintenance but also minimizes the risk of lubrication-related issues, such as leaks or contamination.

The Flanged design of the Bush allows for easy installation and secure fixation, ensuring stability and durability during operation. The PAF material used in the bearing exhibits excellent wear resistance and friction-reducing properties, further enhancing its performance and lifespan.

The FMB2021.5 size of this bearing makes it suitable for a wide range of applications, including machinery, equipment, and other industrial components that require a reliable and long-lasting bearing solution.

As a leading supplier of bearings, we pride ourselves on providing high-quality products and exceptional customer service. Contact us today to learn more about the Self-Lubricating Flanged Bush FMB2021.5 PAF Bearing and how it can enhance the performance of your industrial applications. We're here to help you find the perfect bearing solution for your needs.

Flanged Bush FMB2021.5 PAF Bearing

PAF Bearings
SPLIT BUSH BEARINGS FLANGED BUSH FMB 2021.5 , split Flanged Bearing Bush Lined Flange31/OD23*ID20*Length21.5(20+1.5)

Self Lubricating Flanged Bush FMB2021.5 PAF Bearing

pecifications for FMB 2021.5 Flanged Split Bush Bearing - Type
Reference	FMB 2021.5
Brand	BR
Inside Diameter	20mm
Outside Diameter	23mm
Width	21.5mm
Type	Bearing
Weight (KG)	0.020

Schematic for FMB 2021.5 Flanged Split Bush Bearing - Type
B	21.5mm
D	23mm
d1	20mm

FMB2021.5, P

AF20215P10 Split Flanged Bearing Bush Lined 20x23x21.5mm

Self Lubricating Flanged Bush FMB2021.5 PAF Bearing

Self Lubricated Lined Split Bush Bearing

The composite material consists of three bonded layers

1.Steel Backing

2.Porous Bronze Matrix

3.Impregnated and overlaid with Bearing material

The steel backing provides mechanical strength and the bronze inter layer (impregnated with the lead Mixture) provides a strong mechanical bond for the lining. This construction promotes dimensional stability and improves the thermal conductivity, thus reducing the temperature at the bearing surface. During normal operation, a thin film from the lining is transferred to the opposing surface and maintained there throughout the working life of the bearing.

More Information
Inside Diameter	=	20mm
Outside Diameter	=	23mm
Width	=	21.5mm
Flange Diameter	=	30mm
Flange Width	=	1.5mm
Brand	=	NEUTRAL
Manufacturer Part Number	=	FMB2021.5
Image	=	The image represents the series, but may not be the exact part
Alternative Brand	=	In the very unlikely event that we should not have available free stock in the listed brand, then a quality brand will be supplied.

Gleitbuchse mit

Eigenschaften / Abmessungen in mm
Bezeichnung	BM 2515, 2515 , PCM .., PAP ..
Innendurchmesser	25,0
Aussendurchmesser	28,0
Breite	15,0
Ausführung	Geeignet für Trockenlauf, niedriger Reibwert, geringer Verschleißrate, gute Gleiteigenschaften. Bestehend aus einem Stahlrücken mit aufgesinterter, poröser Bronzeschicht und einer Gleitschicht aus . Die Farbe der Beschichtung kann abweichen.
Material	Stahl / Bronze /

Low Friction Bushing Bush, Plain, 25 x 28 x 15 mm

Plain Low Friction Bushing bushes are plain bearing materials that offer a good performance on both wear and friction over a wide range of temperatures, speeds, and radial and axial loads. Low Friction Bushing Bushes are ideal for construction and agricultural machines or for any other application which requires rotating and sliding motions. Usually Low Friction Bushing bushes operate without lubricants and are resistant to most solvents and industrial liquids.

Specifications for 2515 Split Bush Bearing - Type
Reference	MB 2515
Brand	BR
Inside Diameter	25mm
Outside Diameter	28mm
Width	15mm
Type	Bearing
Weight (KG)	0.0001

Schematic for 2515 Split Bush Bearing - Type
B	15mm
D	28mm
d1	25mm

Metal-Polymer Composite Self-lubricating Bushing Material
Steel Back + Porous Bronze Sinter + + Lead

Metal-Polymer Anti-Friction Plain Bearings Characteristics

self-lubricating bushings offer very good wear and low friction performance over a wide range of loads, speeds and temperatures in dry running conditions
Bushing material suitable for lubricated applications
Anti-friction bearing suitable for linear, oscillating and rotating movements
Approved to standard FAR 25.853 and FAR 25.855 (Federal Aviation Regulations) and ASTM E162:2016 – surface flammability testing for aircraft interior applications
Tested acc. to ASTM E595/ECSS-Q-ST-70-02C - Outgassing properties of materials used in Spacecraft equipment
Approved to standard DIN EN 1797 and ISO 21010 (Cryogenic Vessels – Gas/Material Compatibility) for piping, valves, fittings and other components in both gaseous and liquid oxygen for up to maximum temperature of 60°C and oxygen pressure of 25 bars. Contact Viiplus for further details.

AVAILABILITY

Bearing forms available in standard dimensions

Cylindrical bushes
Flanged bushes
Thrust washers
Flanged washers
Sliding plates

Metric bearings and imperial bushings made to order: standard bushing forms in special dimensions, half-bushings, special shapes obtained by stamping or deep drawing, customized bushing designs.
