High Tensile Brass Bushings CuZn25Al5Mn4Fe3 ASTM B505 C86300 Self Lubricating Bearing

Product Categories
JIAXING VIIPLUS INTERNATIO NAL TRADING CO.,LTD
Contact Now

High Tensile Brass Bushings CuZn25Al5Mn4Fe3 ASTM B505 C86300 Self Lubricating Bearing

  • 1
  • 2

Brand Name : VIIPLUS

Model Number : Rg7 Bronze Bushing CC493K

Certification : DIN G-CuSn 7 ZnPb

Place of Origin : Bushing Manufacturer

MOQ : Standard Size Bushing No Minimum Order Quantity

Price : Bushings High Quality Price Ratio B2B

Payment Terms : T/T, Western Union

Supply Ability : Buy Bronze Bushings Online,Bronze Bearings

Delivery Time : 7-25 work days

Packaging Details : EXPORT CARTON WOOD PALLET WOODEN CASE

Bushing Material : High Tensile Brass Bearings

Bushing Application : Parts Repair and Fabrication Services (Heavy Equipments, Automotive, Shipping industry, Machinery, Etc)

Code : ASTM B505

Material Properties : C86300 Bushings

Bushings Size : 8~400mm

Size : customized items

Bearing Bushing Factory Price : tiffany@viiplus.com

Self-lubricating Bearing Bushing Manufacturer : https://www.viiplus.com/

High Light : Self-Lubricating Sintered Bronze Bushing

characteristic : Bronze bushings with grease reservoirs ( BRO-MET, FB090, BRM10, WB800)

Bush Bearings Manufacturers Suppliers Exporters : plain bearings. Long, maintenance-free service, manufactures bushings in various designs and from different materials. tiffany@viiplus.com, Bushings - Configure and purchase - https://www.viiplus.com/

Contact Now

High Tensile Brass Bushings CuZn25Al5Mn4Fe3 ASTM B505 C86300 Self-Lubricating Bearings are precision-engineered components designed to provide exceptional performance in a wide range of industrial applications. These bushings are made from CuZn25Al5Mn4Fe3 alloy, which is known for its high tensile strength, wear resistance, and corrosion resistance.

The self-lubricating feature of these bearings ensures smooth and reliable operation, even in high-load and high-speed conditions. This is achieved through the material's inherent lubricating properties, which reduce friction and heat generation, extending the lifespan of the bushings.

The bushings adhere to the strict standards set by ASTM B505, ensuring consistent quality and performance. They are also manufactured in accordance with the C86300 specification, which guarantees their compliance with industry-recognized standards for brass bushings.

Wh used in heavy machinery, automotive components, or other industrial applications, High Tensile Brass Bushings CuZn25Al5Mn4Fe3 ASTM B505 C86300 Self-Lubricating Bearings are an excellent choice for providing superior performance and reliability. Their unique alloy composition and self-lubricating properties make them stand out as a top choice for demanding industrial applications.

Bronze Sleeve Bushings

High Tensile Brass Bushings CuZn25Al5Mn4Fe3 ASTM B505 C86300 Self Lubricating Bearing

CC762S brass bearings is a brass formulated for casting bushings.CC762S CuZn25Al5Mn4Fe3 high tensile brass bearing & bushing with graphite or without graphite size 8mm~400mm.It is an extremely hard material sliding bronze bearings, especially suited for machine elements submitted to the highest demands.The closest international standard is the ASTM B505 C86300.

Chemical Requirements
Copper
Alloy
UNS No.		 Composition, % max, except as indicated
Nickel
Copper Tin Lead Zinc Iron Including Aluminum Manganese Antimony Sulfur Phosphorus Silicon
Cobalt
C86300 60.0–66.0 0.20 0.20 22.0–28.0 2.0–4.0 1.0A 5.0–7.5 2.5–5.0 ... ... ... ...
C90500 86.0–89.0 9.0–11.0 0.30 1.0–3.0 0.20 1.0A 0.005 ... 0.20 0.05 0.05B 0.005
C91100 82.0–85.0 15.0–17.0 0.25 0.25 0.25 0.50A 0.005 ... 0.20 0.05 1.0B 0.005
C91300 79.0–82.0 18.0–20.0 0.25 0.25 0.25 0.50A 0.005 ... 0.20 0.05 1.0B 0.005
C93700 78.0–82.0 9.0–11.0 8.0–11.0 0.8 0.7C 0.50A 0.005 ... 0.50 0.08 0.10B 0.005
A In determining copper minimum, copper may be calculated as copper plus nickel.
B For continuous castings, phosphorus shall be 1.5 % max.

C Iron shall be 0.35 % max. when used for steel-backed.

High Tensile Brass Bushings CuZn25Al5Mn4Fe3 ASTM B505 C86300 Self Lubricating Bearing

Material Properties

Bushing & Bronze Bearings Diameter: Make to Order,Size As per as customers' request Grade: CuZn25Al5Mn4Fe3.Cu (Min): 60%

Application: In marine industry bushin,hydraulic bearings industry and related sliding bearing industries

High Tensile Brass Bushings CuZn25Al5Mn4Fe3 ASTM B505 C86300 Self Lubricating Bearing

Facility

We operate some of the most advanced, precise equipment available.

Special brass bearing manufacturer

EN CC762S (CuZn25AI5Mn4Fe3-C) Brass Bearings

Chemical composition

% min.

% máx

Al

3,0

7,0

Cu

60,0

67,0

Fe

1,5

4,0

Mn

2,5

5,0

Ni

3,0

Zn

Remainder

P

0,03

Pb

0,2

Sb

0,03

Si

0,1

Sn

0,2

High Tensile Brass Bushings CuZn25Al5Mn4Fe3 ASTM B505 C86300 Self Lubricating Bearing

Closest International Standards Bearing & Bushing Materials

Country Standard Alloy Code Type Status
Alemania DIN 1709 : 1981 CuZn25Al5
Australia AS 1565 : 1996 C86300 C86300 High tensile brass
China GB 1176 : 1987 CuZn25Al6Fe3Mn3
España UNE 37-103-2 : 1981 CuZn25Al6Fe3Mn3 C-2625
Hungría MSZ 8579 : 1984 CuZn25Al6Fe3Mn2 KsröAl6
ISO ISO 1338 : 1977 CuZn25Al6Fe3Mn3
Polonia PN / H-87026 : 1991 CuZn26Al6Mn3Fe2Ni1,5 [ MA62 ]
USA ASTM B 584 : 1998a et alia C86100 C86100
USA ASTM B 584 : 1998a et alia C86300 C86300
USA ASTM B 30 : 2000 C86300 C86300 SAE 430B

Are you interested in our products?


Manufacturer of bronze quality parts
Bronze Bearing Production
Sectors
Bronze Bearings
Self Lubricating Bronze Bearings

Product Name
Precision Parts Aluminum Copper Fit Sleeve Brass Bronze Bushing
Material
1)Metal:Stainless steel,Steel(Iron,)Brass,Copper,Aluminum
2)Plastic:POM,Nylon,ABS,PP
3)OEM according to your request
Surface treatment
Anodized different color,Mini polishing&brushing,Electronplating(zinc plated,nickel plated,chrome plated),Power coating&PVD coating,Laser marking&Silk screen,Printing,Welding,Harden etc.
Tolerance
±0.01mm
process
CNC machining,Auto lathing/turning,Milling,Grindin, Tapping Drilling,Bending,Casting,Laser cutting
Certificate
ISO9001:2008,SGS, ROHS,ISO9001:2015
Delivery Time
10-12days
MOQ
1000
